XC968-EV
| Availability: | |
|---|---|
| Quantity: | |
Product Introduction
The XC968-EV electric loader is not merely an "electric" product; it is also an "intelligent green construction solution" oriented towards the future. Through technological revolution, it has brought disruptive advantages in environmental protection, economy, noise control and intelligence, making it a strategic choice for customers to achieve transformation and upgrading, cost reduction and efficiency improvement, and fulfill social responsibilities.
Product Advantage
Zero emissions, environmental pioneer: Fully powered by electricity, there is no exhaust emission during operation, meeting the most stringent environmental protection requirements. It can be widely applied in highly environmentally demanding confined Spaces (such as tunnels and underground areas) and urban regions.
Extremely low operating costs: Electricity costs are much lower than fuel costs. At the same time, regular replacement items such as engine oil and filters have been eliminated, significantly reducing maintenance and upkeep costs. The overall energy consumption cost can be reduced by more than 50%.
Super power and efficient operation: The motor can instantly output the maximum torque, with an extremely fast response speed, stronger lifting force and higher work efficiency.
Ultimate tranquility and excellent comfort: The operating noise of the motor is far lower than that of the diesel engine, greatly improving the working environment for drivers and reducing the noise impact of the equipment on the surrounding community.
Intelligent management: Integrated with an advanced remote management system, it can monitor in real time the vehicle's location, battery level, working status, energy consumption and other data, achieving intelligent management of the fleet.
Technical Parameters
| Description | Specifications | Unit |
| Rated load | 5800 | kg |
| Bucket capacity | 3.2 | m3 |
| Operating mass | 18800 | kg |
| Rated power of the motor | 270 | kW |
| Dumping height | 3370 | mm |
| Dumping range | 1200 | mm |
| Wheelbase | 3350 | mm |
| Wheel tread | 2250 | mm |
| Maximum breakout force | 170 | kN |
| Maximum traction force | 174 | kN |
| Total cycle time | 9.7 | s |
| Minimum turning radius (tire center) | 6005 | mm |
| Tire specification | 23.5-25 | / |
| Steering angle | 40 | ° |
| Overall machine dimensions (L×W×H) | 8660×2996×3475 | mm |
| Forward I/II | 18/36 | km/h |
| Reverse I/II | 18/36 | km/h |
Product Uses
In confined Spaces such as tunnels and underground mines: There is no need to worry about ventilation and exhaust gas issues, ensuring the health of construction workers.
Industries with high requirements for environmental cleanliness, such as food, medicine, and cold chain: Eliminate fuel pollution.
Urban construction and municipal engineering: Reduce noise interference to residential areas and carry out construction in areas with high environmental protection requirements at night.
Ports, docks and steel mills: Carry out bulk cargo handling to reduce operating costs.
Green demonstration parks and new energy projects encouraged by the state: highly consistent with the overall environmental protection concept of the project.
Product Operate Guide
Start：
Insert the key and turn it to the "ON" position. The entire vehicle will be powered on and the system will conduct a self-check.
After self-checking for no abnormalities, step on the brake pedal, confirm that the gearshift lever is in neutral (N gear), and press the "Start" button. The vehicle is Ready (the Ready light comes on).
"Walk：
Release the electronic handbrake.
Select the forward (F) or reverse (R) gear.
Slowly release the brake pedal and gently press the accelerator pedal. The vehicle begins to move smoothly. The acceleration response of the electric loader is very direct. When operating it for the first time, it should be stepped on gently.
FAQ
A: XC968-EV typically adopts the industry-leading three-electricity system:
• Battery system: Equipped with a large-capacity and highly safe lithium iron phosphate battery pack, the battery capacity typically reaches over 525 kWh, supporting both fast and slow charging.
• Drive motor: It adopts a high-power permanent magnet synchronous motor with high peak power, which can continuously output strong power and has a working efficiency far exceeding that of traditional fuel-powered equipment.
• Electronic Control System: Integrated with an intelligent electronic control management system, it precisely controls the vehicle's energy distribution, motor speed, working mode, etc., to maximize energy efficiency.
A: Equipped with multiple intelligent technologies, such as:
• Intelligent energy management system: Automatically optimize energy consumption and extend battery life.
• Telematics system: It can monitor the vehicle's location, working status, battery level, fault alarm and other information in real time through the cloud platform.
• Intelligent diagnostic system: Rapid self-checking and fault location, reducing downtime.
• Multiple working modes: such as economic mode, standard mode, heavy-load mode, etc., can be selected according to different working conditions to balance efficiency and energy consumption.
A: The battery life is closely related to the working condition and load. Under typical heavy-load working conditions (such as mine loading and unloading), it can generally support continuous high-intensity operations for 4 to 6 hours. If the working conditions are lighter, the battery life will be longer. The specific duration needs to be determined based on the actual operation cycle and intensity.
A: Supports fast charging.
• DC fast charging: With a dedicated DC charging station, it takes approximately 1 to 1.5 hours to fully charge the battery from a low level.
• AC slow charging: Using conventional AC power, it usually takes about 8 to 10 hours and is suitable for replenishing energy when parking at night.
A: The battery pack has been meticulously designed and rigorously tested, ensuring a long cycle life. The typical designed service life can reach over 8 years or thousands of charge and discharge cycles. The specific degree of attenuation and replacement cost should be referred to the official warranty terms. Batteries can be utilized in a stepped manner and can still be used as energy storage devices after attenuation.
