Product Introduction
Safety is prioritized with multiple protective devices meeting international standards like CE and GOST. Premium materials and advanced manufacturing ensure equipment reliability. Optimized hydraulic and electronic control systems minimize energy consumption. Modular design simplifies maintenance, reducing long-term operational costs.
Product Advantage
Have multiple job safety protection measures. Complies with CE, GOST and other safety requirements. Optimized structural design for lighter weight Optimized hydraulic system with less energy consumption. On the train and get off the use of a separate operation of the valve, the use of rotary valve to select the oil, on and off interlock, effectively reducing the risk of misuse. In addition to the car to operate the seat arrangement of the turntable side, with the turntable infinite rotation, with better control of the field of vision.
Technical Parameters
|
Item
|
Unit
|
Parameter
|
|
Max Lifting Capacity
|
kg
|
16000
|
|
Max Lifting Moment
|
t.m
|
40
|
|
Recommend Power
|
kw
|
37
|
|
Max Oil Flow of Hydraulic System
|
L/min
|
63
|
|
Max Pressure of Hydraulic System
|
Mpa
|
31.5
|
|
Oil Tank Capacity
|
L
|
250
|
|
Crane Weight
|
kg
|
5000
|
|
Installation Space
|
mm
|
1500
|
|
Rotation Angle
|
°
|
360°All Rotaion
|
Product Uses
1. Material Handling in Mining Quarries
The SQ16ZK4Q's 16-ton lifting capacity adequately handles most heavy materials, ores, and equipment in mining quarries. Its 360° full rotation capability enables flexible operation in confined spaces, adapting to complex and variable site conditions. Multiple safety protection devices ensure operational safety in such high-risk environments.
2. Urban Construction and Municipal Engineering
This crane excels in space-constrained conditions like urban construction sites, municipal pipeline installations, and old neighborhood renovations. Its compact design and agile slewing capabilities minimize disruption to daily life and traffic while handling pipe and small equipment hoisting tasks.
3. Logistics Transfer and Cargo Handling
The SQ16ZK4Q facilitates material loading, unloading, and transfer operations in ports, terminals, and logistics parks. Its rapid lifting and slewing functions boost efficiency, while advanced hydraulic and electronic control systems optimize energy utilization and reduce operational costs.
4. Industrial Plant Equipment Installation and Maintenance
In petrochemical and industrial plant environments, this crane facilitates the installation, inspection, and maintenance of large-scale equipment. Its modular design simplifies maintenance and component replacement, minimizing downtime and ensuring production continuity.
5. Other Complex and Specialized Applications
With its excellent maneuverability and adaptability, the SQ16ZK4Q can also handle diverse complex scenarios, such as fulfilling specialized tasks through the addition of various attachments. Its structural design has been optimized for specific markets, enhancing strength and rigidity to accommodate a broader range of regional operating conditions.
Product Operate Guide
Before operating the SQ16ZK4Q, fully extend the outriggers and ensure the ground is solid and level. Maintain the crane in a level position at all times during operation, and strictly prohibit any overload operations. Manipulate the boom steadily and slowly, paying particular attention to maintaining safe distances from surrounding obstacles. Rotation operations should be performed at a slow, uniform speed, avoiding abrupt stops or turns. Regularly inspect wire rope wear and the condition of structural component connections. After completing operations, retract the boom, secure the hook, and maintain daily equipment maintenance records.
FAQ
1. WHAT SHOULD I DO IF THE BATTERY IS LOW ON POWER?
Check if the alternator is charging properly, if the battery is worn out, or if there are electrical leaks in the circuit. Inspect the charging system, replace the battery, and locate any leaks.
2. HOW DO I TROUBLESHOOT A MALFUNCTIONING LIGHTING SYSTEM?
Check if the fuse is blown, if the bulb is damaged, or if the wiring connections are secure. Replace the fuse and bulb, and inspect the wiring.
3. WHAT SHOULD I DO IF THE MACHINE LACKS TRACTION?
Check the transmission fluid level and inspect the clutch or torque converter for faults. Top up transmission fluid and repair the drivetrain system.
4. HOW DO I RESOLVE HEAVY STEERING?
Check the steering hydraulic system pressure and inspect the steering gear for faults. Adjust system pressure and repair the steering gear.
5. WHAT IF THE CONTROL LEVER IS UNRESPONSIVE?
Check if the pilot pressure is normal and if the lever mechanism is worn. Adjust the pilot pressure and replace worn components.
6. HOW TO RESOLVE AUTOMATIC BOOM LOWERING?
Check if the boom cylinder seals are damaged and if the hold valve is functioning properly. Replace the cylinder seals and repair the hold valve.
