Product Introduction
It features the breakthrough to the limitations of the style design in forklift industry with its unique and brand new structural appearance of XG. The application of XG XEC electrical control matching technology provides multiple modes of speed selection for various different working conditions. Better elevating speed with new safety mode is design for easy and convenient operation. Through accurate electrical controlled adjustment, the integrated drive axle can achieve the gradeability up to 17%.
Product Advantage
* The application of XG XEC electrical control matching technology not only improves the smoothness of vehicle starting, acceleration and brake as well as the comfort of operation, but also enhance the protection of materials and personnel. The hydraulic system is applying dual-seaI structure of 24° cone and O-ing, effectively preventing the system from any possible leakage. It is also using the most advanced sixth generalion hydraulic cylinder to ensure the safety and reliability of operation.
* The covering parts can be removable without any help of the tools, providing more space and convenience of maintenance.
* On the basis of ergonomics, it is the first time in the industry configured with dual DOF (degree of freedom) steering control mechanism of XG independent intellectual property right to create a more oomfortable experience of operation and control.
Technical Parameters
| Model | Unit | XCB-L18 |
| Rated capacity | kg | 1800 |
| Load center distance | mm | 500 |
| Size | Max.lifting height | mm | 3000 |
| Free lifting height | mm | 145 |
| Mast tilt angle front/rear | ° | 6/12 |
| Length fork excluded | mm | 2125 |
| Width | mm | 1130 |
| Mast height | mm | 1985 |
| Overhead guard height | mm | 2130 |
| Min.under clearance | mm | 110 |
| Wheel base | mm | 1380 |
| Min.Turning radius | mm | 1880 |
| Performance | Travelling speed loaded/unloaded | km/h | 13/14 |
| Lifting speed loaded/unloaded | mm/s | 330/450 |
| Gradeability loaded/unloaded | % | 15/17 |
| Motor&Battery | Motor | Drive motor power | kW | 8 |
| Pump motor power | kW | 10 |
| Battery | Voltage | V | 48 |
| Amphere | Ah | 270/315/360 |
Product Uses
Manufacturing industry: Material handling in production workshops of automobiles, electronics, home appliances, etc.
• Warehousing and logistics: Stacking and handling of goods in e-commerce warehouses, distribution centers, and third-party logistics.
• Cold chain industry: Goods handling in cold storage rooms (special configuration for cold storage is required).
• Food and beverage: Production and storage environments with high requirements for environmental hygiene.
• Airports and railway stations: Transfer of luggage and goods.
Product Operate Guide
1. Startup
Make sure the handbrake is in the tensioned position.
Insert the key into the electric lock and rotate it to the "ON" position.
Observe the self-check on the dashboard to confirm that there are no faults and the alarm light will come on.
Make sure the battery is fully charged.
2. Driving
◦ Select direction: Use the direction switch (usually on the right hand side) to choose forward (F) or backward (R).
The vehicle will emit the corresponding warning sound.
Release the handbrake: Step on the foot brake and release the parking handbrake.
◦ Control speed: Slowly press the accelerator pedal and the vehicle will start moving. The deeper you step on the pedal, the faster you go.
Release the pedal to perform electric braking (energy recovery).
◦ Steering: Operate the steering wheel smoothly. When turning, be sure to slow down in advance.
FAQ
1.What is the rated load capacity of this forklift? What is the maximum lifting height?
A: The rated load capacity of XG XCB-L18 is 1.8 tons. The standard maximum lifting height is usually 3 meters, but different heights of the mast can be selected according to customer requirements (such as 4 meters, 5.5 meters, etc.). For specific details, please consult the dealer.
2.What advantages do electric forklifts have over internal combustion forklifts?
A: The main advantages include
• Environmentally friendly and zero-emission: Suitable for indoor use and places with high environmental requirements.
• Low operating costs: Electricity costs are much lower than fuel costs, and maintenance costs are also lower.
• Low noise: Improve the working environment and reduce noise pollution.
• High energy efficiency: The AC motor has high efficiency and is equipped with energy regenerative braking function.
3.How is its climbing ability?
A: The full-load climbing capacity of XG XCB-L18 typically (usually) is no less than 15%, which can meet the ramp requirements within most factory areas and warehouses.
4.Can the forks be moved sideways?Can other attachments be installed?
A: The standard configuration forks are fixed. However, a **** side shifter can be optionally equipped (facilitating the slight left and right movement of the forks for easy loading and unloading). In addition, it can also install most standard attachments, such as paper roll clamps, push-pull devices, rotators, etc. However, after installing the attachments, the rated lifting capacity needs to be reduced accordingly to ensure safety.
5.Is it suitable for use in cold storage?
A: The standard model is not suitable. If it is necessary to operate in a low-temperature cold storage environment (such as -30°C), the "cold storage-specific type" must be selected. This type of vehicle will use special steel, hydraulic oil, seals and electrical components to prevent condensation water and equipment brittleness, ensuring reliability and safety in extremely low temperatures.
6.If a forklift breaks down, how can I quickly troubleshoot it?
The dashboard of XG XCB-L18 is equipped with A function to display fault diagnosis codes. When a malfunction occurs, the dashboard will display specific error codes (such as E01, E02, etc.). You can refer to the fault code table in the vehicle manual to initially determine where the problem lies.
