Product Introduction
This 90° bend connector with part number 801139304 is a professional pipeline connecting fitting specially designed for heavy-duty engineering machinery. It adopts integrated forming technology, features stable structure and good sealing performance. It is mainly used to change pipeline flow direction, smoothly connect oil pipes, water pipes and gas pipes inside equipment. Perfectly matched with XE2000 mining excavator and other related models, it is an essential wear-resistant replacement spare part for construction and mining machinery.
Product Advantages
High strength solid material, anti-pressure and anti-deformation, not easy to crack under high load working condition.
Excellent sealing property, effectively prevent oil leakage, water leakage and air leakage.
Standard original size, direct installation without modification, high fitting degree.
Wear resistance, corrosion resistance and high temperature resistance, adapt to harsh mining site environment.
Smooth inner wall, reduce fluid flow resistance, ensure stable pipeline transmission.
Long service life, low failure rate, greatly reduce equipment later maintenance cost.
Product Parameter Table
Item | Specification |
Product Name | 90 Degree Bend Connector |
Part Number | 801139304 |
Bending Angle | 90° |
Main Material | High-strength alloy steel |
Surface Treatment | Anti-rust oil spraying |
Applicable Fluid | Hydraulic oil, cooling water, air |
Working Pressure | High pressure resistance |
Matching Model | XE2000 Mining Excavator |
Feature | Integrated forming, leak-proof |
Application Scenarios
Internal hydraulic pipeline connection of XE2000 mining excavator
Engineering machinery equipment pipeline steering connection
Mining site heavy equipment oil circuit and water circuit layout
Large construction machinery pipeline turning assembly
Industrial heavy-duty vehicle fluid pipeline transition connection
Excavator maintenance replacement and equipment assembly supporting use
User Guide
Before installation, cut off equipment power and release residual pressure inside the pipeline for safe operation.
Clean the connecting port and remove dirt, iron filings and impurities to avoid affecting sealing effect.
Align the interface of 90 degree bend connector with pipeline port, install sealing ring correctly.
Screw and fix evenly with professional tools, do not over-twist to avoid thread damage.
After installation, check all connecting positions, start equipment and test pipeline operation.
Regularly check tightness and sealing condition during daily use, replace in time if aging occurs.
FAQ
Q: Which equipment does 801139304 bend connector fit for?
A: It is specially suitable for XE2000 series mining excavator, also matches most same-spec engineering machinery.
Q: Will this elbow joint leak oil easily?
A: Adopt precise interface and matching sealing parts, good leakproof performance, no leakage under normal working pressure.
Q: Can I install this fitting by myself?
A: Yes, standard size, simple structure, follow installation steps to finish replacement quickly.
Q: What environment is this bend connector suitable for?
A: Adapt to high dust, high temperature, heavy load harsh working environment such as mine and construction site.
Q: How long is the service life of this 90 degree bend connector?
A: With normal use and regular inspection, long service life, stable performance and not easy to damage.
Q: Is there any difference between this replacement part and original part?
A: Made strictly according to original standard size, same installation size and use effect, cost-effective for replacement.
