XCB-D20
| Availability: | |
|---|---|
| Quantity: | |
Product Introduction
The XCB-D20 is a 20-tonne truck-mounted crane transport vehicle, combining cargo-carrying and lifting capabilities. With a maximum rated lifting capacity of 20 tonnes, its main boom extends to over 10 metres. Equipped with an efficient hydraulic system, it delivers precise micro-movement and stable operation. Featuring a lightweight design compatible with standard lorry chassis, it offers convenient relocation and excellent manoeuvrability. Suited for urban infrastructure, logistics handling, equipment installation, and landscaping projects, it combines transport efficiency with lifting capability, making it an effective solution for both urban and rural engineering and logistics operations.
Product Advantage
Exceptional Lifting Capacity: Maximum rated lifting capacity of 20 tonnes, with a fully extended main boom reaching over 10 metres. Ample lifting moment ensures capability for medium to heavy-duty hoisting operations.
Integrated Cargo and Lifting Functionality: Combines cargo transport and lifting capabilities into a single vehicle, delivering multi-purpose utility that significantly enhances overall engineering and logistics efficiency.
Precision Control: Efficient hydraulic system with excellent micro-movement performance. Smooth hoisting, luffing, and slewing operations ensure high lifting accuracy.
Convenient Relocation: Mounted on standard truck chassis with lightweight design, offering excellent manoeuvrability for flexible urban/rural site transfers.
High Reliability and Durability: Reinforced critical structural components, stable hydraulic and electrical systems, low failure rate, and high operational availability.
Economical and Practical: Low maintenance costs, fuel-efficient operation, adaptable to diverse scenarios, and short investment payback period.
Technical Parameters
| Model | - | XCB-D25 | XCB-D20 | XCB-D35 |
| Power Type | - | Diesel | Diesel | Diesel |
| Rated Load Capacity | Q(kg) | 2500 | 2000 | 3500 |
| Load Centre | C(mm) | 500 | 500 | 500 |
| Rated Lift Height | H(mm) | 3000 | 3000 | 3000 |
| Free Lifting Height | H3(mm) | 160 | 160 | 150 |
| Mast Height | H1(mm) | 1995 | 1995 | 2075 |
| Overall Width | W2(mm) | 1150 | 1150 | 1285 |
| Overhead Guard Height | H4(mm) | 2120 | 2140 | 2140 |
| Turning Radius (Outside) | R(mm) | 2240 | 2170 | 2495 |
| Travel Speed (Full/No Load) | km/h | 17/19 | 17/19 | 18/19.5 |
| Lifting Speed (Full Load/unload) | mm/s | 550/580 | 550/580 | 450/500 |
| Total Weight | kg | 3670 | 3330 | 4780 |
| Battery | V/Ah | 12/80 | 12/80 | 12/80 |
| Engine Model | - | XINCHAI | XINCHAI | ISUZU |
| Other Options | - | 2-Stage/3-Stage Full Free Wide View Mast | ||
Product Uses
Urban Infrastructure and Municipal Engineering
Road construction, streetlight installation, guardrail erection, landscaping and tree transplanting, small-scale steel structure hoisting.
Equipment Handling and Installation
Loading, unloading, and positioning of small-to-medium equipment including factory machinery, generator sets, air compressors, air conditioning units, and transformers.
Logistics and Building Materials Transport
Loading, unloading, and transhipment of steel, stone, precast components, containers, and large pipe fittings. Transport and hoisting completed in a single vehicle journey.
Rural and Urban Engineering & Agricultural Operations
Rural housing construction, bridge building, livestock facility development, and transfer of agricultural machinery and heavy materials.
Emergency Response and Rescue Operations
On-site obstacle clearance, material hoisting, and rapid deployment of compact emergency equipment for flexible, efficient operations.
Landscaping, Signage, and Municipal Maintenance
Signage installation, landscape rock hoisting, and horticultural landscaping suitable for confined workspaces.
Product Operate Guide
Prior to operation, inspect the vehicle, outriggers, hydraulic system, wire ropes, and safety devices. Confirm the ground is firm and level, fully extend the outriggers and ensure they are securely supported. Start the engine and idle to warm up. Adjust the boom angle and outreach according to the working conditions. Overloading, diagonal pulling, and travelling under load are strictly prohibited. During operation, execute movements steadily and gradually. Control lifting, luffing, and slewing speeds to avoid abrupt stops or turns. Maintain constant vigilance over the load moment limiter. Obey the instructions of the designated signalman at all times; personnel must not remain beneath the boom or suspended load. Upon completion, retract the boom and outriggers, securing them firmly. Clean the equipment and maintain thorough inspection records. Strictly adhere to safety operating procedures to ensure the safety of personnel and machinery.
FAQ
A: To ensure power performance and reliability, the XCB-D20 usually selects diesel engines from well-known domestic brands such as Yuchai, Xinchai or Weichai, which meet the National III emission standards. They are powerful, easy to maintain and have low costs.
A: Yes. Tire type: Solid tires (suitable for flat and hard roads, wear-resistant and puncture-resistant) or pneumatic tires (suitable for uneven roads, with good shock absorption).
A: Three checks must be conducted:
1. Visual inspection: Tire pressure/wear, whether the forks are cracked or deformed.
2. Oil inspection: The levels of engine oil, coolant, hydraulic oil and brake fluid.
3. Function check: Whether the lights, horn, handbrake and foot brake are functioning properly.
A: The minimum turning radius is a key indicator for measuring the flexibility of forklifts. The design of the XCB-D20 typically ensures a relatively small turning radius, enabling it to make flexible turns and U-turns even in narrow aisles and between shelves, significantly enhancing space utilization and operational efficiency.
A: The maintenance cycle is usually calculated based on working hours (hours). Please strictly follow the regulations in the operation manual.
Daily maintenance: The routine inspection as mentioned above.
50 to 250 hours (first maintenance) : Change the engine oil and oil filter.
500 hours: Replace the diesel filter, engine oil and oil filter, and check all performance.
1000 hours/half a year: Replace the hydraulic oil, hydraulic oil filter, transmission oil (if applicable), and clean the air filter element, etc.
2,000 hours per year: Conduct a more comprehensive inspection and maintenance, including replacing coolant, brake fluid, etc.
• Unable to start: Check if the battery is fully charged, if the wiring connections are loose, and if the fuel has run out.
• Weak lifting power/slow descent: Check if the hydraulic oil level is too low or if the hydraulic oil filter is clogged.
• Deviation in direction: Check if the tire pressure on both sides is consistent and if the wear is even.
In case of any malfunction that cannot be resolved, work should be stopped immediately and professional service personnel should be contacted.
