SQ6.3SK3Q
| Availability: | |
|---|---|
| Quantity: | |
Product Introduction
This machine prioritizes safety, featuring multiple standard safety devices such as an anti-overwind alarm system to significantly enhance operational security. Its advanced hydraulic system ensures smooth, reliable, and easy operation during crane lifting tasks. The unique floating three-point bridge structure design effectively reduces additional stress on the chassis beam during vehicle travel, improving driving safety and extending equipment lifespan.
Product Advantage
Changing the form of previous manipulation and throttle operation individually,Realization of the bilateral handle synchronous and driving throttle acceleration and deceleration automatically, due to the speed change steady,it can easily to carry out the lifting work. Maximum savings in preparation time before and after operation, to ensure that customer's vehicle could be in a driving state in the shortest time, and prevent crane damage accident caused by hoist swing to enhance the safety of driving.
Technical Parameters
| Item | Units | SQ6.3SK3Q |
| Max lifting capacity | kg | 6300 |
| Max lifting moment | T.m | 13.23 |
| Recommend power | kW | 18 |
| Max oil flow | L/min | 25 |
| Max pressure | mpa | 28 |
| Oil Tank Capacity | L | 90 |
| Crane weight | kg | 2226 |
| Installation space | mm | 1050 |
| Rotation angle | degree | 360 |
| Extension length | mm | 9920 |
| Lifting height | mm | 13000 |
Product Uses
1. Municipal and Construction Projects
This crane is suitable for municipal and construction sites, effectively lifting building materials such as precast slabs and steel reinforcement. Its 360° full rotation capability and flexible operation enable efficient work in confined spaces, meeting diverse lifting requirements.
2. Mining and Quarry Operations
In mining and quarry environments, this equipment handles heavy loads like large rocks, timber, and machinery. Its boom sections feature pentagonal or hexagonal cross-sections for superior bending resistance and stability, ensuring reliability in complex, demanding conditions.
3. Landscaping and Timber Transport
This crane is also commonly employed in landscaping projects for transporting large trees and timber. Its outstanding stability and maneuverability ensure safe and efficient loading, unloading, and relocation of forest resources.
1. Factory, Mine, and Equipment Maintenance
In industrial and mining environments, it handles heavy lifting during equipment installation, maintenance, and repairs. Its compact pivot point design saves space, while the user-friendly operating system simplifies operation. Various attachments can be added as needed.
Product Operate Guide
Operating the SQ6.3SK3Q lorry crane requires certification and strict adherence to safety protocols. Before any lift, deploy outriggers to their full width on stable, level ground. Always consult the load chart to ensure the weight and radius are within safe limits. Use smooth, controlled movements with the hydraulic controls. Never lift loads over people and maintain a safe distance from power lines. Regularly inspect the wire rope and hooks for damage.
FAQ
1. HOW TO ADDRESS EXCESSIVELY HIGH EQUIPMENT WATER TEMPERATURE?
Check coolant level, clean the radiator, inspect the water pump and thermostat operation, and clear debris from the radiator exterior.
2. HOW TO RESOLVE BLACK SMOKE FROM THE ENGINE?
Check if the air filter is clogged, verify the fuel injection system is functioning properly, and ensure the turbocharger is operating effectively.
3. HOW TO IMPROVE EQUIPMENT OPERATIONAL EFFICIENCY?
Perform regular maintenance, operate the equipment correctly, and select appropriate operating modes and attachments based on working conditions.
4. HOW TO REDUCE EXCESSIVE FUEL CONSUMPTION?
Maintain optimal engine operating conditions, optimize operating habits, avoid prolonged idling, and perform regular fuel system maintenance.
5. HOW TO ADJUST SLOW EQUIPMENT MOVEMENT?
Check hydraulic system pressure and flow, adjust pump and valve parameters, and ensure the system operates at peak efficiency.
6. WHAT CAUSES EQUIPMENT TO VEER OFF COURSE DURING TRAVEL?
Check if tire pressures or track tensions are consistent, if the braking system exhibits unilateral drag, or if the transmission system has malfunctions.
