NCL3258
| Availability: | |
|---|---|
| Quantity: | |
Product Introduction
Product Advantage
1.Comfortable Driving, Pleasant Enjoyment
* Symmetrical, refined, excellent and ergonomic design, facilitates your driving operation; covering fitings adopt leather package, strong light absorption, no high-light points, reduce visual fatigue.
* Multi-functional configuration, large storage space; strictly control the gap and chromatism, meticulous work; silk stocking airbag seats.
2.Maximum Supporting capacity and practicability
* Golden power assembly-For the economic and reliability, reliable brands engine, Fast gearbox, Steyr axles are adopted for our manufacturing. The range of power output are from 280hp to 420hp to achieve multi-working-condition.
* Modular designed chassis, neat arrangement highly universalizable. Meanwhile, the reliability and convenience of maintenance have been improved.
Technical Parameters
| Dimension | NCL3258 |
| Overall size (length×width×height) | 7910×2490×3150mm |
| Cargobody size (length×width×height) | 5200×2300×1400mm |
| Wheelbase | 3650+1350mm |
| Wheel tread (Front/Rear) | 2032/1848mm |
| Min. ground clearancee | 270mm |
| Kerb mass | 10480kg |
| Gross vehicle weight | 24675kg |
| Rated loading capacityy | 14000kg |
| Max. travel speedd | 80km/h |
| Min. turning diameter | 16m |
| Max. gradeability | 30% |
| Approach angle | 26° |
| Departure angle | 26° |
| Fuel consumption | 28(L/100 km) |
| Engine | 6C280-2, water-cooling, turbocharging and intercooling, Euro II emission standard, direct injection diesel |
| Rated output at 1,900rpmm | 280HP(206kw) |
| Max. torque at 1200r/pm | 1117N.m |
| Rated Fuel consumption | 205g/(KW.h) |
| Rims | 8.00-20 |
| Tyres | 12.00R-20 |
| Operating voltage | 24V |
| Alternator | 70A/28V |
| Batteries | 6-QAW-165 |
| Capacity | 240 L |
Product Uses
Building materials transportation and urban construction: It performs outstandingly in the medium and short-distance transportation of building materials such as sand and gravel, construction waste, and bricks. Its sturdy frame and strong load-bearing capacity can adapt to unpaved roads both inside and outside construction sites.
• Mining operations: In the on-site transportation of heavy objects such as ores and slag, its high reliability is a key advantage. The powerful engine and passability are sufficient to cope with the complex road conditions in the mining area.
• Infrastructure construction: Commonly used in large-scale infrastructure projects such as highways, railways, and water conservancy, it is responsible for the transportation of earthwork and stone materials.
Product Operate Guide
The operation of the NCL3258 dump truck must strictly follow the norms to ensure safety and efficiency. Before starting, be sure to check the hydraulic system, the cargo box locking device and the tire pressure, and make sure the vehicle is parked on a solid and flat ground. When unloading, first open the manual lock hook at the rear door of the cargo box. When the vehicle comes to a complete stop, apply the handbrake, step on the clutch, shift into neutral gear, then turn on the power take-off switch and slowly push the lifting handle to make the cargo box rise at a constant speed. During the lifting process, the engine speed should be kept stable to avoid sudden acceleration. After unloading is completed, the cargo box should be lowered to a fully reset position and confirmed to be locked first, and then the power take-off should be closed.
FAQ
1. WHO ARE WE?
XUZHOU SHANGHENG ENGINEERING MACHINERY CO.,LTD is a leading construction machinery exporter,located in Xuzhou city,Jiangsu province where Xuzhou Construction Machinery Group Inc in. We have the domestic agency rights of them more than 10years,based on the advantage of them,we also estabish long-time business with other famous brands.
2. HOW IS YOUR PRICE COMPARED WITH MANUFACTURERS/FACTORIES?
We work as the leading dealers of various leading China construction machinery manufacturers/ factories, and are constantly treated with best dealership price. From numerous comparison and feedbacks from clients, our price is more competitive than the price from manufacturers/factories.
3. HOW IS YOUR DELIVERY TIME?
In general circumstance, we can have an immediate delivery of regular machines for our clients within 7 days, because we have a variety of resources to check machines in stock, locally and nation widely, and to receive machines in timely manner. But for manufacturers/factories, it will take more than 30 days to produce the ordered machine.
4. HOW SOON CAN YOU RESPOND CLIENT INQUIRIES?
Our team is consisted of a group of diligent and dynamic people, working 247 to respond client inquiries and questions all the time Most problems can be solved within 4 hours while manufacturers/factories will take much longer to give response.
5. WHICH PAYMENT TERMS CAN YOU ACCEPT?
Normally we can work on T/T term or L/ term, sometime DP term.
1)On T/T term, 30% down payment is required in advance, and 70% balance shall be settled before shipment, or against the copy of original B/L for long-term cooperating client.
2)On L/C term, a 100% irrevocable L/ C without "soft clauses"from an international recognized bank can be accepted. Please seek the advice from the individual sales manager whom you work with.
6. WHAT SERVICES CAN WE PROVIDE?
Accepted Delivery Terms: FOB,CFR,CIF；
Accepted Payment Currency:USD,EUR;
Accepted Payment Type: T/T,L/C,Western Union,Cash;
Language Spoken:English,Chinese
7. WHAT PRODUCTS YOU CAN GET FROM US?
Our main products including,wheel loader,backhoe loader,truck crane,crawler crane,tower crane,road roller,motor
grader,excavator,bulldozer,forklift,dump truck,trailer,tractor truck,special vehicle ,Marine Machinery and all of their spare parts.
