Product Introduction
Safety is prioritized through high-strength steel construction and multiple safeguards (including interlocking controls for cab entry/exit, CE/GOST-compliant safety design, and alarm installations), minimizing operational errors and enhancing safety. Its optimized hydraulic system (rated pressure 22MPa, max flow 25L/min) delivers lower energy consumption with smooth, reliable operation. The three-point bridge design with floating axles effectively reduces additional stress on the chassis beams during vehicle travel, enhancing driving safety and equipment longevity.
Product Advantage
Single cylinder synchronization guy cable technology makes work efficiency higher than before. Advanced development means make sure that the design is very reliable. The more symmetrical center design of pentagon or hexagon boom make it has bigger anti-bending capacity. Compact hinge point design takes up smaller space. The work is more safety after fitted with alarm device. The integer lifting winch improved the work efficiency greatly and prolonged work life of hydraulic system. Float three -point bridge structure design can lower the accessional stress on the chassis when traveling. It has been fitted own powerful slewing of working in diversifying conditions. Anti-slewing impulse equipment makes vehicle running safety.
Technical Parameters
| Parameter Item | Unit | Scale |
| Max Lifting Capacity | kg | 3200 |
| Max Lifting Moment | t.m | 6.72 |
| Recommend Power | kw | 14 |
| Max Oil Flow of Hydraulic System | L/min | 25 |
| Max Pressure of Hydraulic System | Mpa | 22 |
| Oil Tank Capacity | L | 60 |
| Crane Weight | kg | 1150 |
| Installation Space | mm | 850 |
| Rotation Angle | ° | 370 |
Product Uses
1. Construction and Municipal Engineering
This crane is suitable for construction sites and municipal projects, effectively handling the lifting and transport of building materials such as precast slabs and reinforcing bars. Its folding boom design enables flexible operation in confined workspaces, making it ideal for urban construction and environments with limited space.
2. Logistics, Warehousing, and Factory Operations
In logistics yards, warehousing centers, and factory workshops, this equipment facilitates cargo loading/unloading, pallet handling, and equipment installation/maintenance. Its excellent maneuverability (operable via control console or seat, with the seat rotating with the turntable for enhanced visibility) and compatibility with various attachments enable adaptation to diverse lifting tasks and specialized working conditions.
3. Mining and Quarrying (Special Considerations)
This crane can lift rocks, ore, and other materials in mining and quarrying environments. However, special attention must be paid to site levelness, dust levels, and weather conditions (such as high winds). Strict adherence to safety regulations and enhanced equipment maintenance are essential to ensure safety and suitability.
4. Emergency Response and Fire Rescue
This crane model has been deployed on fire department rescue vehicles for transporting rescue equipment or assisting operations. Its 370° full rotation flexibility and reliable hydraulic system offer significant value in emergency scenarios.
Product Operate Guide
Before operating the SQ3.2ZK2, certified personnel must conduct a comprehensive equipment inspection to ensure all components are in good working order and adequately lubricated. During operation, fully extend the outriggers on solid, level ground to achieve stable support. Strictly adhere to the load chart; overloading is strictly prohibited. Operate via the control console or seat with smooth movements, utilizing its 370° full rotation and two-stage boom swing capabilities for precise positioning. Maintain constant awareness of the surrounding environment and avoid hazardous conditions. Perform regular maintenance, focusing on wire ropes, hydraulic systems, and structural component safety.
FAQ
1. HOW TO USE THE INTELLIGENT CONTROL SYSTEM?
Read the operating manual, attend training sessions, gradually familiarize yourself with all functions, and consult technical personnel when encountering issues.
2. HOW TO EXPORT AND ANALYZE DEVICE DATA?
Use a dedicated data cable or wireless transmission device to download and analyze data via the official software platform.
3. HOW TO MAINTAIN THE REMOTE MONITORING SYSTEM?
Ensure the communication module functions properly, perform regular software updates, protect account security, and promptly address alarm notifications.
4. HOW DO I CONFIGURE DEVICE OPERATING PARAMETERS?
Log into the management system with authorized permissions. Modify parameters according to operating procedures, then save and verify changes.
5. HOW DO I USE THE INTELLIGENT DIAGNOSTIC SYSTEM?
Connect the diagnostic device, select the appropriate testing function, follow on-screen prompts, and read/analyze fault codes.
6. WHAT PRECAUTIONS SHOULD BE TAKEN WHEN SERVICING THE BRAKING SYSTEM?
Use specialized tools. Disassemble components in sequence. Replace worn parts. After installation, adjust clearances and conduct functional testing.
