Product Description
XCA300G8‑1 all‑terrain crane delivers reliable heavy‑lifting performance under harsh construction conditions. Its 8‑section 92m telescopic main boom supports safe boom retraction & extension under partial rated load, expanding operation scope and boosting construction efficiency by 30%‑50%. The independent dual‑engine configuration (chassis 405 kW + upper 221 kW) cooperates with G2 electro‑hydraulic energy‑saving system to cut operating fuel consumption by over 30% compared with previous generations. The 10×8×10 multi‑axle chassis supports multiple steering modes, granting outstanding trafficability on muddy, sloped and uneven job‑sites. Variable outrigger technology allows flexible outrigger extension combinations to adapt narrow working space. Equipped with intelligent load‑moment indicator, overload interlock protection, fault self‑diagnosis and full‑function wireless remote control for counterweight & outriggers. Spacious panoramic operator cabin with shock‑absorbing seat optimizes long‑shift operation comfort for heavy‑duty jobs.
Product Advantages
Outstanding Lifting Capacity:
Rated 300‑ton lifting capacity; 92m eight‑section main boom plus optional 36m jib, max lifting height reaches 115.1 m, leading performance within same tonnage class.
Load‑carrying Telescopic Boom:
Realize safe boom extension & retraction under partial load, enlarge working radius and raise site efficiency by 30‑50%.
Dual‑engine G2 Energy‑saving System:
Separate power units for chassis and superstructure; advanced electro‑hydraulic control reduces fuel consumption more than 30%.
Flexible Variable‑support Outrigger:
Supports arbitrary outrigger extension combinations, suitable for limited‑space construction sites while guaranteeing high working stability.
Premium All‑terrain Mobility:
10×8×10 drive‑steering chassis, multi‑mode steering, strong climbing capacity, adapts to rough, muddy and slope working conditions.
Heavy‑load Transfer Capability:
Travel with 34 t counterweight and full outrigger pads, covering above 45% typical working conditions and shortening relocation time on‑site.
Intelligent Safety Protection Suite:
Real‑time load‑moment monitoring, overload cut‑off, fault self‑diagnosis, wireless remote control for auxiliary assemblies.
High‑reliability & Good Part Commonality:
Mature hydraulic and powertrain assemblies; key attachments such as hook, jib and counterweight share compatibility with adjacent tonnage models, lowering spare‑parts cost.
Technical Parameters Table
Item | Specification |
Model | XCA300G8‑1 |
Type | All‑Terrain Crane |
Rated Lifting Capacity | 300 Ton |
Main Boom | 8‑section telescopic boom, 92 m |
Optional Jib Length | 36 m |
Max Lifting Height(Main Boom + Jib) | 115.1 m |
Power Configuration | Dual‑engine: Chassis 405 kW, Upper 221 kW |
Chassis Drive / Steering | 10×8×10 |
Max Travelling Speed | 80 km/h |
Max Gradeability | 60 % |
Travel Operating Weight | 72000 kg |
Control Platform | G2 electro‑hydraulic intelligent control, load‑moment indicator |
Core Feature | Load‑carrying boom extension, variable outrigger support, wireless remote control |
Product Applications
Petrochemical plant heavy‑equipment installation & maintenance
Bridge component hoisting, erection and on‑site repair
Wind‑farm auxiliary hoisting and wind‑turbine maintenance
Large steel‑structure erection for high‑rise buildings
Urban large‑scale infrastructure construction
Power station heavy‑duty equipment lifting
Heavy machinery relocation and emergency rescue projects
FAQ
Q1: What is model and rated lifting capacity of this crane?
A: XCA300G8‑1, XCMG premium‑generation 300‑ton all‑terrain crane.
Q2: What are the core highlights for XCA300G8‑1?
A: It features load‑carrying telescopic boom, variable‑support outriggers, dual‑engine energy‑saving G2 control system and 92‑meter long eight‑section main boom. Heavy‑load transfer function reduces frequent counterweight disassembly and improves overall construction efficiency.
Q3: Can you supply brand‑new or used machines?
A: We mainly provide brand‑new XCA300G8‑1 all‑terrain crane. Used units are available subject to stock; please send inquiry for stock check and quotation.
Q4: What trade terms and lead time do you support?
A: FOB, CIF, CFR terms are acceptable. Lead time depends on stock and production schedule, please submit inquiry for latest delivery arrangement.
Q5: What after‑sales services can be provided?
A: Complete operation‑maintenance manuals, remote technical consultation, spare‑parts supply and video‑based technical guidance. Overseas on‑site service can be negotiated.
Q6: Can we select optional accessories?
A: Yes. Auxiliary jib, different counterweight combinations, wireless remote‑control kit and other attachments can be configured according to your lifting‑project requirements.
Q7: What advantages does all‑terrain crane compare with truck crane?
A: All‑terrain crane adopts multi‑axle all‑wheel‑steering chassis with superior off‑road capability. It can travel and operate on uneven, muddy construction sites while maintaining high lifting performance, more suitable for complex large‑scale projects.
