Product Description
The XCS55S container reach stacker is a high-performance heavy-duty logistics handling equipment tailored for 55-ton ultra-heavy container stacking and transshipment work. The whole machine adopts high-rigidity integral frame and thickened high-strength steel boom structure, paired with precision welding and integral forging technology, effectively improving overall structural stability, anti-fatigue and anti-impact performance during long-term high-load operation. The optimized boom inclination design realizes flexible lifting and luffing adjustment, adapting to multi-layer container stacking and high-precision cargo positioning requirements.
Equipped with a matched high-power power system and intelligent load-sensitive hydraulic system, the XCS55S achieves fast response, stepless speed regulation and stable power output. It supports 425mm/s no-load lifting speed and 250mm/s full-load lifting speed, with efficient cargo handling and low energy consumption. The multi-stage hydraulic buffer device effectively reduces jitter and impact during lifting, falling and luffing processes, avoiding cargo shaking and ensuring safe and stable operation. The optimized hydraulic pipeline layout minimizes leakage risks and greatly improves the durability of core hydraulic components.
The whole machine adopts humanized cab design with wide field of vision, shock absorption and noise reduction, providing a comfortable operating environment for long-hour continuous work. The intelligent integrated control system simplifies operating logic with low operation threshold, realizing precise control of walking, lifting, stacking and steering. Equipped with professional container spreader and stable anti-slip clamping structure, it firmly locks containers to prevent offset and falling. All finished equipment passes strict full-load aging tests and all-weather working condition simulation tests, fully adapting to high-intensity, long-cycle and harsh outdoor operation of port terminals.
Product Advantages
55-ton Ultra-high Load Capacity:
Standard 55-ton heavy-duty rated load, supporting rapid handling and multi-layer stacking of full-load standard containers and ultra-heavy bulk cargo, meeting high-intensity port logistics operation demands.
Efficient Hydraulic Lifting Performance:
Advanced load-sensitive hydraulic system achieves fast lifting response, with 425mm/s no-load lifting speed and stable full-load operation, greatly improving container handling efficiency and reducing single-cargo operation time.
Flexible Boom Adjustment Range:
The boom supports 0°–60° flexible inclination adjustment, adapting to different stacking heights and cargo placement angles, realizing high-precision positioning and flexible stacking operation.
Excellent All-terrain Passability: Optimized heavy-duty chassis and high-grip tire design, with strong gradeability and stable walking performance, adapting to uneven yard ground, rainy and snowy slippery roads and other complex port working environments.
Ultra-high Operational Stability:
High-rigidity integral frame + reinforced boom structure effectively resists working vibration and load impact. Professional container spreader ensures firm clamping and zero-offset stable stacking.
Energy-saving & Low-consumption Design:
Intelligent power matching and load-sensitive hydraulic technology automatically adjust power output according to load changes, effectively reducing idle energy consumption and lowering long-term operating costs.
Durable & Low Failure Rate:
Core components adopt industry-leading high-quality accessories, with wear-resistant, anti-corrosion and anti-impact performance, adapting to all-weather outdoor high-intensity operation and extending service life.
Humanized Intelligent Operation:
Wide-view shock-absorbing cab and simplified intelligent control system reduce operator fatigue, supporting long-hour continuous and efficient logistics operation.
Technical Parameters
Item | Specification |
Model | XCS55S |
Equipment Type | 55 Ton Heavy-duty Container Reach Stacker |
Rated Lifting Capacity | 55 Ton |
Boom Inclination Range | 0° ~ 60° |
No-load Lifting Speed | 425mm/s |
Full-load Lifting Speed | 250mm/s |
No-load Lowering Speed | 360mm/s |
Full-load Lowering Speed | 300mm/s |
Working System | Intelligent Load-sensitive Hydraulic System |
Structural Feature | High-rigidity Integral Frame + Reinforced Boom Structure |
Operation Mode | Intelligent Integrated Cab Operation |
Applicable Scenarios | Port Terminal, Container Yard, Logistics Park, Industrial Heavy Cargo Storage |
Core Accessories | Professional Container Spreader, Anti-slip Clamping Device, Intelligent Monitoring System |
Product Applications
Port Terminal Container Operation:
Rapid lifting, transshipment and multi-layer stacking of 20ft/40ft standard containers at international port terminals, supporting high-frequency and high-efficiency container turnover work.
Logistics Yard Storage & Stacking:
Regular stacking, sorting and inventory management of container goods in large logistics parks and freight yards, maximizing yard space utilization.
Heavy Bulk Cargo Handling:
Stable lifting and short-distance transshipment of ultra-heavy industrial bulk cargo, mechanical equipment and large freight containers in industrial logistics bases.
Freight Station Rapid Turnover:
Efficient loading and unloading and relocation of import and export goods at large freight stations, improving overall logistics transportation efficiency.
Special Cargo Precise Positioning:
High-precision placement and stacking of oversized and super-heavy cargo, adapting to strict placement standards of professional logistics and warehousing scenarios.
All-weather Outdoor Operation:
Stable handling work in complex environments such as open-air ports, windy and dusty yards, and rainy and snowy weather, meeting all-weather logistics operation requirements.
FAQ
Q1: What is the core positioning of the XCS55S reach stacker?
A: The XCS55S is a professional 55-ton heavy-duty container reach stacker, specially designed for high-intensity container stacking and heavy cargo transshipment. It features high load capacity, fast operating speed and strong environmental adaptability, solving the problems of low efficiency and insufficient load capacity of traditional handling equipment, and is a core efficiency-enhancing equipment for port logistics.
A: The XCS55S adopts an advanced load-sensitive hydraulic system, with fast no-load lifting speed and stable full-load operation. The multi-stage buffer design eliminates operating jitter and cargo shaking. The system can intelligently adjust power output according to load changes, ensuring high efficiency while reducing energy consumption and equipment wear.
Q3: What working environments is the XCS55S suitable for?
A: It is fully adapted to all-weather high-intensity operation scenarios such as open-air port terminals, container yards, large logistics parks and industrial heavy cargo storage bases. It can work stably on uneven ground, windy, dusty, rainy and snowy complex working conditions with strong environmental adaptability.
Q4: Can it realize multi-layer container stacking?
A: Yes. The boom supports 0°–60° flexible inclination adjustment, matched with high-precision hydraulic control system and professional container spreader. It can realize stable multi-layer stacking and accurate positioning of standard containers, effectively improving yard space utilization.
Q5: What is the delivery cycle and after-sales service?
A: The standard delivery cycle of XCS55S is 25–35 working days. We provide 12 months official factory warranty, lifelong free technical guidance, remote fault diagnosis and cost-price spare parts supply, ensuring stable and long-term operation of customer equipment.
Q6: Is the equipment easy to operate for long-hour work?
A: Definitely. The XCS55S is equipped with a wide-view shock-absorbing and noise-reducing cab and humanized integrated intelligent control system. The operation logic is simple and precise, which effectively reduces operator fatigue and supports long-hour continuous high-intensity logistics operation.
