Product Description
The XGL80-6S long-span tower crane is a high-efficiency construction lifting equipment developed targeting large-area building sites and wide-span engineering scenarios. The whole machine adopts thickened high-strength square steel tube tower sections and integral welding stress relief technology, effectively improving overall structural rigidity, torsion resistance and long-term high-altitude anti-fatigue performance. The customized 80m ultra-long jib structure greatly expands the horizontal working coverage, realizing one-machine full-site coverage for large construction bases and significantly reducing equipment transition and positioning frequency.
Equipped with a mature intelligent variable-frequency stepless speed regulation system, the XGL80-6S achieves smooth and jitter-free hoisting, luffing and slewing movements. The optimized hydraulic and electrical matching system ensures sensitive response and stable power output, avoiding material shaking and impact damage during high-altitude lifting. It is equipped with a reliable hydraulic automatic climbing system, supporting fast layered heightening and on-site rapid assembly, which greatly shortens the construction preparation cycle and improves overall project progress. The large-capacity steel rope design meets the continuous lifting requirements of high-rise buildings.
The whole machine adopts standardized modular split structure, with regular component size and compact packaging volume, which greatly reduces cross-region transportation and storage costs. The topkit disassembled structure features simple installation, convenient daily maintenance and strong site adaptability, which can adapt to uneven site foundation and complex urban construction environments. In terms of safety configuration, the crane is equipped with a complete set of limit protection systems including torque limit, height limit and amplitude limit, as well as emergency braking device, realizing full-range intelligent safety monitoring. All equipment undergoes strict factory full-load testing and wind resistance simulation to ensure stable and safe long-term high-intensity outdoor operation.
Product Advantages
80m Ultra-long Super Span Jib:
Industry-leading 80m extra-long jib realizes ultra-wide horizontal coverage, covering large-area construction sites in one time, avoiding frequent crane movement and greatly improving construction efficiency.
Stable 6-ton Heavy-load Performance:
Standard 6-ton max lifting capacity with optimized force balance structure ensures stable lifting of concrete, steel structure and heavy building materials, adapting to diverse construction lifting demands.
High Far-end Operation Stability:
Optimized jib stress structure and balance system ensure reliable operation at ultra-long working radius, solving the problem of insufficient stability of ordinary long-jib cranes at the jib end.
Intelligent Variable-frequency Smooth Control:
Full-action stepless speed regulation realizes smooth start, stable operation and precise stop, effectively reducing construction vibration and improving high-altitude positioning accuracy.
Efficient Hydraulic Climbing System:
Automatic hydraulic heightening design simplifies on-site assembly steps, saves manual hoisting and heightening time, and accelerates the overall construction progress of high-rise projects.
Strong Site Adaptability:
Modular disassembled structure adapts to complex urban construction, open-air large sites and limited-access working environments, with flexible deployment and wide application scenarios.
Low Operation & Maintenance Cost:
Mature structural design and standardized accessories reduce failure rate. Convenient disassembly and maintenance lower later operation cost, achieving high comprehensive cost performance.
Full-coverage Safety Protection:
Equipped with complete torque, height and amplitude limit systems and emergency braking function, realizing automatic early warning and power-off protection to eliminate high-altitude construction safety hazards.
Technical Parameters
Item | Specification |
Model | XGL80-6S |
Crane Type | Long Jib Topkit / Hammerhead Tower Crane |
Max Lifting Capacity | 6 Ton |
Max Jib Length | 80m |
Jib End Tip Load | 0.8 Ton |
Max Free-standing Height | 40m |
Max Attached Height | 180m |
Max Hoisting Speed | 85m/min |
Luffing Speed | 48/24m/min |
Slewing Speed | 0~0.6r/min |
Rope Capacity | 380m |
Tower Section Size | 1.6m × 1.6m × 2.8m |
Mast Type | High-strength Integral Tower Section |
Control System | Intelligent Variable-frequency Stepless Speed Control |
Safety Device | Torque Limiter, Height Limiter, Amplitude Limiter, Emergency Brake System |
Product Applications
Large-span Industrial Park Construction:
Full-coverage material lifting and steel structure installation for large industrial parks, logistics warehouse clusters and large-span factory buildings, adapting to ultra-wide site layout.
Super Large Residential Community Projects:
Continuous material transportation and auxiliary hoisting for large-scale residential blocks and supporting commercial facilities, eliminating frequent crane relocation.
Municipal & Public Infrastructure:
Lifting operations for large municipal projects, public buildings, stadiums and comprehensive service facilities with wide construction coverage.
High-rise Commercial Building Construction:
Stable high-altitude material handling and component positioning for mid and high-rise office buildings, shopping malls and comprehensive commercial buildings.
Phased Large-area Engineering:
Suitable for large construction sites requiring phased expansion and continuous construction, realizing long-term stable full-site coverage operation.
Complex Open-air Construction Sites:
Adaptable to open-air windy environments and large-area flat sites, supporting all-weather high-intensity continuous construction work.
FAQ
Q1: What is the biggest feature of the XGL80-6S compared with conventional tower cranes?
A: The core advantage is the 80m ultra-long jib ultra-wide coverage design. Compared with ordinary 60m-63m jib tower cranes, it covers a larger construction area, greatly reducing equipment moving and debugging frequency, and significantly improving the overall construction efficiency of large-span projects. It maintains stable 6-ton lifting capacity and far-end operation stability, achieving both wide coverage and high load performance.
Q2: What is the maximum working height of the XGL80-6S tower crane?
A: It features a 40m free-standing independent height without wall attachment, and the maximum attached working height can reach 180m. It fully meets the construction requirements of various mid-rise and high-rise buildings, and is suitable for most large-scale industrial and municipal engineering projects.
Q3: Is the long-jib design stable during high-altitude operation?
A: Yes. The XGL80-6S adopts optimized jib force structure and integral balance system, with enhanced wind resistance and structural rigidity. It effectively reduces jib shaking during long-span operation. Matched with variable-frequency smooth control technology, the whole machine operates stably with high positioning accuracy, fully meeting high-standard high-altitude construction requirements.
Q4: Is the equipment convenient for transportation and on-site installation?
A: Absolutely. It adopts standardized modular split structure with regular and unified components, which is convenient for container transportation and reduces logistics cost. The supporting hydraulic automatic climbing system realizes fast on-site heightening and assembly, saving installation time and labor cost, with high construction flexibility.
Q5: What safety protection functions does the XGL80-6S have?
A: The crane is equipped with a complete intelligent safety protection system, including torque limiting protection, height limiting protection, amplitude limiting protection and emergency braking device. It can automatically alarm and cut off power when overloaded or beyond working range, effectively preventing high-altitude operation risks and ensuring standardized and safe construction.
Q6: What projects is the XGL80-6S most suitable for?
A: It is specially designed for large-span and large-area construction scenarios, including large industrial parks, super-large residential communities, municipal public buildings, high-rise commercial complexes and phased large-scale engineering projects. It shows extreme efficiency advantages in wide-site construction.
