Product Introduction
XGS20ACK-Li is a self-propelled straight boom aerial work platform powered by high-performance lithium battery. It delivers zero emission, ultra-low noise and longer continuous working time compared with traditional lead-acid models. Featuring 20.5m maximum working height, 13.2m horizontal outreach and 300kg rated load, this unit boasts flexible movement, stable operation and excellent cross-country performance. It is an ideal eco-friendly solution for indoor and outdoor high-altitude operations in construction, municipal engineering, venue maintenance and other fields.
Product Advantages
Lithium Battery Power: Lightweight design, fast charging, long service life and extended working hours, lower daily maintenance cost.
Superior Working Range: 20.5m max working height and 13.2m max outreach, covers various long-distance high-altitude tasks.
Large Load Capacity: 300kg rated capacity, can hold 2 operators plus working tools to improve working efficiency.
Eco & Quiet Operation: Full electric drive with no exhaust gas and low noise, suitable for environmentally restricted areas.
Strong Terrain Adaptability: 45% gradeability, four-wheel drive and axle balance system for stable travel on rough and sloped roads.
Flexible Rotation: 360° continuous turntable rotation and 160° platform swing, enabling all-round positioning without blind spots.
Smooth Hydraulic System: Load-sensing hydraulic technology ensures steady boom movement and effective energy saving.
Reliable Driving Structure: AC drive and differential steering reduce tire wear and prolong overall service life.
Product Specifications
Item | Unit | XGS20ACK-Li |
Max. Working Height | m | 20.5 |
Max. Platform Height | m | 18.5 |
Max. Horizontal Outreach | m | 13.2 |
Rated Platform Load | kg | 300 |
Platform Dimension | mm | 1830×760×1150 |
Overall Dimension (L×W×H) | mm | 9800×2490×2640 |
Total Weight | kg | 8350 |
Power Source | - | 51.2V 412Ah Lithium Battery |
Travel Speed | km/h | 0 - 4.8 |
Max. Gradeability | % | 45 |
Turntable Rotation Angle | ° | 360° Continuous |
Platform Swing Angle | ° | 160 |
Boom Luffing Angle | ° | -65 ~ +70 |
Outer Turning Radius | m | 5.0 |
Max. Tail Swing | mm | 1630 |
Application Scenarios
Municipal Maintenance: Repair of street lamps, traffic signals and bridge inspection.
Large Venues: Roof maintenance, lighting and audio system installation for stadiums, exhibition centers and airports.
Industrial Workshops: Steel structure installation, pipeline and equipment maintenance, high-level cleaning work.
Building Construction: Exterior wall work, glass curtain wall installation and other overhead construction tasks.
Power & Landscaping: Power line maintenance, photovoltaic station inspection and tree trimming.
Commercial Premises: High-altitude cleaning and decoration installation in shopping malls, hotels and large lobbies.
Operation Guide
Pre-operation Inspection
Check the remaining battery power to ensure sufficient electricity for operation.
Examine tires for normal pressure and surface damage.
Confirm hydraulic oil level is within standard range and no leakage occurs.
Check safety guardrails and platform door, make sure all safety locks are fully functional.
Operating Steps
Turn on the main power switch and wait until the system completes self-check.
Drive the machine to the designated working area and engage the parking brake firmly.
Operate control levers slowly to lift, extend and rotate the boom to the target position.
Fine-tune the platform angle for precise positioning.
After finishing work, retract the boom to the fully stowed position first, then cut off the main power.
Safety Regulations
Do not exceed the rated load; maximum 2 persons are allowed on the working platform.
Operate only on solid and flat ground. The ground slope shall not exceed 5 degrees.
Stop all operations immediately when wind speed exceeds 12.5m/s.
Operators must wear safety helmets and safety harnesses during high-altitude work.
Inspect safety sensors and limit devices regularly to guarantee normal protection function.
FAQ
Q1: What are the highlights of XGS20ACK-Li compared with lead-acid battery models?
A: It adopts professional lithium battery pack. It features lighter weight, faster charging speed, longer cycle life and longer continuous working time. It requires almost no regular maintenance, which is more suitable for long-time and frequent operation.
Q2: How long can it work continuously and how much time does it take to fully charge?
A: It can work continuously for 6 to 8 hours under standard working conditions. The fast charging mode only needs 2 to 3 hours to get fully charged.
Q3: Is this machine available for indoor use?
A: Yes. Pure lithium electric design produces zero exhaust gas and low running noise, totally compliant with indoor and enclosed working environments.
Q4: What is the maximum climbing capacity?
A: The maximum gradeability reaches 45%. Equipped with four-wheel drive and axle balance structure, it can run stably on muddy, gravel and sloped roads.
Q5: Can you provide customized services?
A: Customization is supported. We can adjust platform size, guardrail height and body color as required. Fast charging interface and remote monitoring system are optional accessories.
Q6: What about the warranty terms?
A: The whole machine is warranted for 12 months or 2000 working hours (whichever comes first). The lithium battery enjoys 36 months of warranty, and we provide long-term technical support and maintenance for core components.
