Product Introduction
The XT604 is mainly targeted at individual farmers, planting cooperatives and other users, and is suitable for various working environments such as paddy fields and dry fields. Its design goal is to offer a more competitive price and more economical operating costs while ensuring sufficient power and reliability, making it a cost-effective choice for users to achieve mechanized production.
Product Advantage
1.Economical and practical power system
Engine: Usually equipped with mature and reliable engines from well-known domestic brands (such as Quanchai, Changchai, etc.).
These engines have low fuel consumption, are easy to maintain, have an abundant supply of spare parts and low cost, effectively reducing the purchase and maintenance costs for users.
The transmission: It adopts conventional transmission configurations such as 8 forward gears +2 reverse gears or 8F+8R (with crawl gear), with reasonable gear Settings, which can meet the needs of different working speeds. The operation is simple and easy to understand.
2. Solid and reliable chassis and transmission
◦ Body structure: It adopts a reinforced chassis and transmission system. Although it is lighter than the KAT series, it still ensures durability under common working conditions.
Drive mode: 4×4 four-wheel drive, combined with hydraulic power steering. It has a small turning radius at the edge of the field, is easy and flexible to operate, and performs well in terms of passability and traction in muddy paddy fields and soft dry fields.
Technical Parameters
|
Engine model
|
Xinchai 4D32RT30
|
|
Engine power
|
44.2kw
|
|
Traction force
|
≥ 18kn
|
|
Wheel base
|
2075mm
|
|
Maximum front counterweight
|
156kg
|
|
Maximum rear counterweight
|
164kg
|
|
Minimum service mass
|
2530 (cab)/2385 (safety rack) kg
|
|
Overall dimensions
|
3860*2495*2640
|
Product Uses
Rotary tillage and harrowing operations in paddy fields/dry fields
• Intertillage management operations such as sowing and fertilizing
• Field and short-distance road transportation
As a power source, it drives fixed operation machinery such as water pumps and balers
Medium-sized management operations for orchards and vegetable gardens
Product Operate Guide
The XT604 tractor is easy to operate and emphasizes practicality. Check the oil and tire pressure before starting. It adopts an 8+ 2-speed transmission with clear gear positions. Combined with hydraulic power steering, it is flexible and effortless to operate. It is equipped with a standard dual-speed PTO (540/720 or 540/1000 revolutions per minute), making it easy to match agricultural tools such as rotary tillers. The control lever of the hydraulic hoist is located on the right side, providing sufficient lifting force and efficient hanging of farm tools. The cab offers a wide field of vision and a sunshade can be optionally installed. When in operation, select the appropriate gear based on the load. Regular maintenance can ensure optimal performance and long-term durability.
FAQ
1.What drive form does this tractor have? What's the horsepower?
A: It is of 4-wheel drive (4×4) form, with a rated power of 60 horsepower. It is a medium-sized tractor and is very suitable for medium-load operations in both paddy and dry fields.
2.What model is the transmission? How many gears are there?
A: Usually, the standard configuration is a regular transmission with 8 forward gears and 2 reverse gears. Some models may be optionally equipped with more gears (such as 8 forward +8 reverse). For specific details, please consult the dealer. The gear Settings fully meet the common operation requirements such as rotary tillage and transportation.
3.How many rotational speeds does the power output shaft (PTO) have?
A: It is equipped with a standard dual-speed power output shaft. Common configurations are 540 revolutions per minute and 720 revolutions per minute (or 540/1000), which can be switched by handle to match the speed requirements of different agricultural tools (such as rotary tillers and seeders).
4.How comfortable is the cab?
A: A closed cab (with air conditioning) or a folding sunshade can be optionally equipped as needed. The cab is fully functional and can provide a good field of vision and basic driving and riding comfort.
5.What should be noted in daily operation and maintenance?
Operation: Preheat the engine thoroughly before operation. Select the appropriate gear according to the load to avoid overloading.
Maintenance: Regularly replace the engine oil, oil filter, diesel filter and air filter in strict accordance with the instructions. Check the tire pressure and any leaks after work every day.
6.Which specific tasks is it suitable for?
A: It is highly suitable for various operation scenarios such as rotary tillage, harrowing, sowing, fertilizing, field management, and short-distance transportation. It is a versatile tool for both farmers and small and medium-sized farms.
