QY25K5C
| Availability: | |
|---|---|
| Quantity: | |
Product Introduction
QY25K5C truck crane is widely used for lifting operations in general engineering projects, such as construction sites, urban
renewal, communication and transportation, ports, bridges, oil fields and mines, as well as complex working environments.
Product Advantage
The QY25K5C features a high lifting capacity and a long boom reach, making it suitable for lifting heavy loads at significant heights.
Equipped with a telescopic boom that can extend to considerable lengths, this crane allows for efficient lifting and precise placement of materials.
Its exceptional load chart and precise control systems ensure safe and accurate lifting operations.
Technical Parameters
| Description | Unit | Parameter value | |
| Overall length | mm | 12850 | |
| Overall width | mm | 2550 | |
| Overall Height | mm | 3480 | |
| Wheel Base | mm | 4500+1350 | |
| Track | mm | 2074/1834/1834 | |
| Total vehicle mass in travel configuration | kg | 33000 | |
| Axle load | Front axle | kg | 7400 |
| Rear axle | 12800 | ||
| Engine rated power | kw/(r/min) | 221/2200 | |
| Engine rated torque | N.m/(r/min) | 1250/1400 | |
| Max. travel speed | km/h | 90 | |
| Min. turning diameter | m | 21 | |
| Min. ground clearance | mm | 250 | |
| Max. grade ability | % | 40 | |
| Approach angle | ° | 11 | |
| Departure angle | ° | 13.5 | |
| Braking distance (at 30 km/h, full load ) | m | ≤10 | |
| Oil consumption per 100km | L | ≤30 | |
Product Uses
1. Urban Construction and Municipal Engineering
The QY25K5C is ideally suited for urban construction sites and municipal projects. Its compact body design and excellent maneuverability enable flexible movement and operation in relatively confined urban areas, facilitating tasks such as steel structure installation and equipment hoisting.
2. Transportation Infrastructure and Bridge Construction
This crane is widely used in transportation infrastructure projects like roads and bridges. It handles operations like lowering rebar cages and hoisting small precast components, providing auxiliary support for large-scale transportation projects.
3. Industrial Sites and Equipment Installation
The QY25K5C is suitable for equipment installation, maintenance, and material handling in industrial facilities (e.g., chemical plants, mines). Its reliable performance and excellent maneuverability make it ideal for precise lifting tasks in industrial environments.
4. Port and Logistics Transshipment
Leveraging its mobility and lifting capacity, the QY25K5C also participates in material transfer and stacking operations at ports and logistics parks.
5. Agricultural Modernization Projects
Case studies demonstrate the QY25K5C series cranes were deployed in Shandong Liaocheng's smart agricultural greenhouse construction project, handling the hoisting and installation of building materials like insulating bricks. This highlights its application potential in agricultural modernization initiatives.
Product Operate Guide
Before operation, check that the outriggers are fully extended and ensure the ground is solid and level. Keep the crane level during operation and never overload it. Extend and retract the boom smoothly, maintaining a safe distance from surrounding obstacles. Rotate slowly and steadily, avoiding abrupt stops or turns. Regularly inspect the wire rope for wear. After completing work, retract the boom, secure the hook, and maintain daily equipment maintenance records.
FAQ
1. WHO ARE WE?
XUZHOU SHANGHENG ENGINEERING MACHINERY CO.,LTD is a leading construction machinery exporter,located in Xuzhou city,Jiangsu province where Xuzhou Construction Machinery Group Inc in. We have the domestic agency rights of them more than 10years,based on the advantage of them,we also estabish long-time business with other famous brands.
2. HOW IS YOUR DELIVERY TIME?
In general circumstance, we can have an immediate delivery of regular machines for our clients within 7 days, because we have a variety of resources to check machines in stock, locally and nation widely, and to receive machines in timely manner. But for manufacturers/factories, it will take more than 30 days to produce the ordered machine.
3. WHAT PRODUCTS YOU CAN GET FROM US?
Our main products including,wheel loader,backhoe loader,truck crane,crawler crane,tower crane,road roller,motor
grader,excavator,bulldozer,forklift,dump truck,trailer,tractor truck,special vehicle ,Marine Machinery and all of their spare parts.
4. AFTER STARTING IN WINTER, DOES THE EXHAUST PIPE EMIT LARGE AMOUNTS OF WHITE SMOKE THAT LINGERS FOR A LONG TIME?
This may indicate a slightly damaged cylinder head gasket, allowing coolant to seep into the combustion chamber where it evaporates and is expelled.
5. DURING ENGINE ACCELERATION, AN AIR LEAK SOUND IS HEARD NEAR THE INTAKE MANIFOLD?
Loose or cracked connections in the intake system between the turbocharger and intercooler or engine.
6. AFTER REPLACING THE AIR FILTER, ENGINE POWER HAS DECREASED?
Check if the air filter assembly seals properly or if the filter element model is correct. Inferior filters may cause greater intake resistance.
