XE80D 8 Ton Small Mini Micro Crawler Excavator

Product Introduction

The XE80 is a compact tracked hydraulic excavator primarily designed for small-scale construction projects such as municipal infrastructure development and agricultural land renovation. This model has an operating weight of 7,425 kg, a bucket capacity ranging from 0.14 to 0.34 cubic meters, and is equipped with a B3.3 engine delivering a rated power of 60 kW, meeting National Emission Standard III requirements. The machine dimensions are 6,155 × 2,220 × 2,618 millimeters, with a maximum digging depth of 4,140 millimeters, a maximum unloading height of 5,100 millimeters, and a travel speed of 4.2 km/h.

Product Advantage

Ecological and economical

Adopting new environmental friendly Yanmar engine, low speed torque, low fuel consumption, high operating efficiency, reliable and durable. The advanced load-sensitive control system, low energy consumption.

Multiple applications

Short tail design and short slewing radius can achieve flexible operation in confined space. Multiple additional configurations to adapt to a variety of operating requirement.

Comfortable operational experience

Fresh air conditioning system to ensure the appropriate temperature. Toughened glass cockpit with good safety view. Detailed design concept improves comfort.

Technical Parameters

Product Uses

1. Municipal and Road Maintenance

The XE80D is ideal for a variety of precision tasks in urban environments, such as road surface repair, cable and pipeline installation, small-scale earthwork, and site leveling. Its compact dimensions and short tail swing design enable it to maneuver and operate flexibly in narrow streets and crowded construction sites, effectively minimizing disruption to surrounding traffic and the environment.

3. Agricultural Water Conservancy and Landscape Engineering

In agricultural water conservancy projects, the XE80D is commonly used for digging irrigation channels, clearing silt, and performing land leveling and renovation. For landscape gardening projects, it can assist in tree planting, terrain fine-tuning, and other precision tasks. Its low ground pressure characteristic helps protect vegetation and hardened surfaces.

4. Diverse Attachment Applications

The XE80D can expand its functionality by installing different attachments (such as breakers, grapples, etc.). This enables it to not only perform conventional excavation but also handle concrete breaking, light demolition, material handling, and other diverse tasks, achieving multi-functional use and adapting to a wider range of working conditions.

Product Operate Guide

To maximize the XE80D's performance, first take advantage of its short tail swing design for agile operation in confined spaces. Familiarize yourself with the intelligent power control system and select the appropriate mode based on working conditions to balance efficiency and fuel consumption. During operation, maintain smooth and precise movements. Make full use of the quick connectors to easily swap out attachments such as breakers and grapples, expanding its multifunctional applications. Regularly inspect the filters and undercarriage components, and keep the equipment clean. This will significantly enhance the equipment's reliability and your operational satisfaction.

FAQ

1. HOW IS YOUR DELIVERY TIME?

In general circumstance, we can have an immediate delivery of regular machines for our clients within 7 days, because we have a variety of resources to check machines in stock, locally and nation widely, and to receive machines in timely manner. But for manufacturers/factories, it will take more than 30 days to produce the ordered machine.

2. WHICH PAYMENT TERMS CAN YOU ACCEPT?

Normally we can work on T/T term or L/ term, sometime DP term.

1)On T/T term, 30% down payment is required in advance, and 70% balance shall be settled before shipment, or against the copy of original B/L for long-term cooperating client.

2)On L/C term, a 100% irrevocable L/ C without "soft clauses"from an international recognized bank can be accepted. Please seek the advice from the individual sales manager whom you work with.

3. WHAT PRODUCTS YOU CAN GET FROM US?

Our main products including,wheel loader,backhoe loader,truck crane,crawler crane,tower crane,road roller,motor

grader,excavator,bulldozer,forklift,dump truck,trailer,tractor truck,special vehicle ,Marine Machinery and all of their spare parts.

4. DOES THE HYDRAULIC SYSTEM PRODUCE SEVERE VIBRATION AND NOISE DURING EQUIPMENT OPERATION?

Check for excessive air ingress in the hydraulic oil (air leaks in the suction line) or excessive suction resistance in the hydraulic pump (clogged filter element).

5. DOES THE ACTUATOR EXHIBIT “CRAWLING” OR JERKING MOTION?

Possible causes include air in the oil circuit, uneven internal friction resistance in the cylinder (e.g., scoring), or unstable control signals.

6. IS JOYSTICK OPERATION HEAVY OR FEEDBACK FORCE INCONSISTENT?

Fault in the pilot control system. Check pilot pump pressure, pilot filter element, pilot oil circuit relief valve, and the pilot control valve itself.
