XE150WB
| Availability: | |
|---|---|
| Quantity: | |
Product Introduction
XE150WB has used a new generation of independent researched and developed controllers as well as a low-noise pump and especially considered the matching between the engine and the low-speed load to make full use of the engine power, improve the working efficiency and effectively reduce the fuel consumption. The reliability during heavy-load operations can be satisfied by virtue of its lightweight chassis with high rigidity and strengthened key parts.
Product Advantage
1. Equipped with a new generation of high-efficiency direct injection engine.
2. Using highly professional design and analysis tools, combined with bench tests, to ensure that our machines are strong and durable.
3. The highest breakout force on the loading end is leading the industry by 15%~20% compared with like models.
4. Fully functional, ergonomically designed man-machine driving and driving environment, equipped with high intensity cab certified with ROPS.
Technical Parameters
| Model | Unit | XE150WB |
| Engine model | / | QSB4.5 |
| Output power of engine | Kw/r/min | 104/2000 |
| Operating Weight | KG | 14000 |
| Max.torque/engine | N.m | 586 |
| Displacement | L | 4.5 |
| Fuel tank capacity | L | 250 |
| Rated flow of main pump | L/min | 2x160 |
| Pressure of main safety valve | Mpa | 31.4/34.3 |
| Hydraulic tank capacity | L | 135 |
| Slewing speed | r/min | 12 |
| Digging capacity of tcuket | KN | 95 |
| Digging capacity of tcuket rod | KN | 72 |
| Min.turning radius | mm | 6500 |
| Rated speed | KM/h | 11/33 |
| Gradient capability | % | 70 |
| A Total length | mm | 7778 |
| B Total width | mm | 2495 |
| C Total heigth | mm | 3305 |
| Counterweight ground clearance | mm | 1230 |
| Min.ground clearance | mm | 355 |
| Min.tail swing radius | mm | 2300 |
| Wheelbase | mm | 2800 |
| Track gauge | mm | 1920 |
| Total width of chassis | mm | 2495 |
| Distance between front axle and turning center | mm | 1700 |
| Hood height | mm | 2430 |
| The maximum digging depth of dozer | mm | 105 |
| Max. digging radius | mm | 7780 |
| Min. swing radius | mm | 7570 |
| Max. digging height | mm | 8190 |
| Max. dumping height | mm | 5855 |
| Max. digging depth | mm | 4630 |
| Maximum depth cut for 2240mm(8 ft) level bottom | mm | 4325 |
| Max. vertical wall digging depth | mm | 4150 |
Product Uses
The XE150WB wheeled hydraulic excavator is powerful, agile, and compact, capable of handling a variety of working environments. Its dimensions comply with road regulations and transportation requirements. It plays an important role in airports, ports, oil fields, urban construction, agricultural water conservancy, and rapid repair, bringing customers substantial value.
Product Operate Guide
Welcome to the XCMG XE150WB excavator! Before operation, please familiarize yourself with the control levers:
The left lever controls the boom and swing, while the right lever controls the arm and bucket.
Start by practicing smooth operation in low-speed mode, then switch to high-efficiency mode once you are proficient.
The cab is equipped with an intelligent display screen for real-time monitoring of equipment status.
Use the automatic idle function appropriately to save fuel.
Ensure the machine remains level during operation to guarantee safety and efficiency.
If you have any questions, please contact after-sales service at any time. Wishing you a pleasant operation!
