Product Introduction
The TY230 bulldozer is a classic model that has been tested by the market for a long time. It doesn't have too many fancy functions. Instead, it has pushed reliability, power performance and economy to the extreme, making it a truly "money-making machine" that can create stable value for users. If you need a device that can handle heavy tasks, is sturdy and durable, and has a low overall operating cost, the TY230 is a choice that will never go wrong.
Product Advantage
* The machine features reasonable layout, excellent performance and advanced technology.
* Higher engine power reserves efficiency, bigger torque output, lower fuel consumption, while better reliability.
* Hydraulicly controlled drive, automatically speed regulating and non-stop gear shifting.
* The final drive uses triangle Spline and tip relief, crowned gear drive to enhance the balance and the stability of the load of transmission Part.
* The novel hexahedral cab offers excellent visibility, the powerful ventilation and unparalleled dust-free.
Technical Parameters
| Specification/Blade type | Straight-tilt | Angle | U-Blade |
| Operating Weight(kg) | 17400 | 17700 | 17900 |
| Min.Ground Clearance(mm) | 400 | 400 | 400 |
| Min.Tuming Radius(m) | 3.2 | 3.2 | 3.2 |
| Ground Pressure(MPa) | 0.069 | 0.070 | 0.071 |
| Track Gauge(mm) | 1880 | 1880 | 1880 |
| Max.Pulling Force(KN) | 142 | 142 | 142 |
| Grade Ability(°) | 30 | 30 | 30 |
| Blade Capacity(m³) | 4.5 | 4.3 | 8.6 |
| Blade WidthxHeight(mm) | 3416x1145 | 3970x1037 | 4061x1386 |
| Max.Lift(mm) | 1110 | 1095 | 1095 |
| Max.Depth(mm) | 530 | 545 | 545 |
| Max.tilt Adjustment(mm) | ≥860 | ≥400 | ≥400 |
| Pitch Adjustment(°) | 55 | 55 | 55 |
| Capability(m³/H)(Theoreticalvalue 40m) | 247 | 247 | 260 |
| Weight Of Blade(kg) | 2350 | 2450 | 2560 |
Product Uses
•Large-scale mines: ore stripping, waste dump operations, road maintenance.
• Water conservancy and hydropower: Dam filling, cofferdam construction, river course management.
• Infrastructure construction: Filling, excavation and leveling of highway and railway subgrades.
• Port terminals: Site leveling, bulk cargo stacking.
• Large industrial sites: Land leveling in development zones and factory areas.
Product Operate Guide
1. Startup
Make sure all joysticks are in the "neutral" or "locked" position.
Turn the key to the "ON" position and wait for the dashboard to complete its self-check.
Sound the horn as a warning and then start the engine.
Idle for 3 to 5 minutes to preheat the engine and hydraulic system.
2. Turn off the engine
Park the equipment on a flat and safe ground.
Lower the shovel steadily to the ground.
Let the engine idle for 3 to 5 minutes to cool down, then turn the key to the "OFF" position to turn off the engine.
Remove the key and lock the cab.
FAQ
1.What type of transmission system does it use?
A: The TY230 adopts a highly mature hydraulic mechanical transmission system of "hydraulic torque converter + power shift gearbox". This transmission method can automatically adapt to the load, effectively protect the engine, reduce shock, and provide smooth and powerful traction.
2.What brand is the engine? What emission standards does it meet?
A: It is usually equipped with turbocharged diesel engines of top domestic brands (such as Shangchai and Weichai). The currently common TY230 model on the market complies with the "National III" emission standards. (Note: When purchasing, please confirm whether there are new models that meet higher emission standards.)
3.Which working devices can be installed?
A: The standard configuration is a straight-tilt shovel (SU shovel), which is suitable for general bulldozing operations. Angle shovels (S-shaped shovels) (for lateral soil pushing) or U-shaped shovels for environmental sanitation (for large-scale bulk material handling) can be optionally installed as needed.
4.Is it difficult to operate?
A: The operation design is user-friendly. It is usually equipped with a pilot hydraulic control operating system. The operating handle is very lightweight and the force feedback is clear. It features a "single handle" operation mode, making it easy to get started. However, efficient and precise operation still requires professional training and practice.
5.What's the environment like in the cab?
A: The cab has passed the ROPS/FOPS (Anti-rollover/Anti-falling Object) safety certification and has good sealing performance. It is equipped with standard air conditioning, suspended seats and large areas of glass, providing a wide field of vision and a comfortable driving environment, which can effectively reduce operator fatigue.
6.Is daily maintenance convenient?
A: Very convenient.
The design fully takes into account the convenience of maintenance:
The side and rear-opening engine hood provides a spacious maintenance space.
The daily maintenance points for the "three filters" (mechanical filter, diesel filter, and air filter) are centrally arranged and within easy reach.
Centralized lubrication interface (optional) enables quick lubrication of hinge points, saving time and labor.
