XCF3512K
| Availability: | |
|---|---|
| Quantity: | |
Product Introduction
The XCF3512K port container forklift is a flagship product created by XG by integrating advanced technology and mature manufacturing processes. With its powerful performance, outstanding stability, the highest safety standards and humanized design, it can effectively enhance the efficiency of port operations and reduce operating costs. It is a reliable choice for customers to achieve efficient and safe container handling, fully demonstrating XG's strong capabilities in the field of heavy construction machinery.
Product Advantage
1. Intelligent and efficient
Industry-leading electronic control technology can achieve accurate control of load and improve work efficiency. The electronic inching function ensures more accurate stacking operation of goods.
2. Comfortable operation
Fully enclosed cab, shock absorption suspension seat, intelligent temperature regulation high-power cooling and heating air conditioner, single handle control mode, greatly reducing the operating fatigue.
3. Energy conservation and environmental protection
Automatically detect vehicle working conditions, identify dynamic power requirements, actively adjust and control engine speed, ensure that the engine works in the best operating area, and reduce system fuel consumption by 10%.
4. Safe and reliable
The structural design is firm and durable, suitable for loading and unloading heavy loads; The combination of precise weight matching technology and electronic control active protection technology ensures the high stability of the forklift.
Technical Parameters
| Item | Unit | XCF1006K | XCF3512K | XCF2512K |
| Overall weight | kg | 10000 | 45000 | 36000 |
| Rated capacity | kg | 12900 | 35000 | 25000 |
| Maximum lifting height | mm | 3000 | 4000 | 4000 |
| Maximum travelling speed (unloaded\loaded) | km/h | 16/19.5 | 26/30 | 26/30 |
| Maximum lifting speed (unloaded\loaded) | km/h | 380/410 | 300/400 | 250/300 |
| Load center | mm | 600 | 1200 | 1200 |
| Minimum turning radius | - | 525 | 1100 | 550 |
| Fork dimensions | mm | 1220×175×80 | 2400×300×125 | 2440×250×110 |
| Fork adjustment range | mm | 440-2140 | 920-2850 | 785-2780 |
| Engine Brand | - | TAD1151VE | VOLVO | VOLVO |
Product Uses
Container yards at ports and docks
International container transshipment station
Large-scale logistics park
Heavy steel structure and equipment manufacturing plant
Other industrial sites that require heavy handling
Product Operate Guide
To operate the XCF3512K forklift, one must undergo professional training and hold a valid certificate. Before starting the operation, it is essential to conduct a round-around inspection to ensure that the tires, lifting gear and hydraulic system are in normal condition. After starting, observe the alarm light on the dashboard to ensure there are no faults. When operating, use the pilot hydraulic control handle to smoothly control lifting, tilting and walking. Overloading is strictly prohibited. When moving containers, the lifting gear must be fully locked. During driving, pay attention to maintaining a low center of gravity, turning slowly, and always observe the surrounding environment. After the operation, the forks should be lowered to the lowest position, the brake should be applied, and the power supply should be turned off. Strictly adhering to safety regulations is the prerequisite for efficient operation.
FAQ
A: The rated lifting capacity of XCF3512K is 35 tons (35,000kg). It can handle 20-foot and 40-foot international standard containers with ease and efficiency, meeting the mainstream operation demands of ports.
A: Usually equipped with high-efficiency diesel engines from world-class brands (such as Weichai or Cummins), it has strong power. Its fuel consumption is competitive among similar products and it meets China's National III/IV and above emission standards, being environmentally friendly and highly efficient.
A: It is equipped with an original imported heavy-duty hydraulic automatic transmission (AT) as standard, which is easy to operate, has smooth gear shifting, can effectively reduce the driver's labor intensity, and is suitable for the frequent start-stop conditions in ports.
A: The cab adopts a humanized design, with spacious interior and wide field of vision. Equipped with suspended seats, automatic air conditioning and low-noise design, it can greatly enhance the driver's comfort and reduce fatigue from long working hours.
A: Very convenient. From the very beginning of the design, maintenance convenience was taken into consideration. An open hood was adopted, making key maintenance points (such as the oil filter and air filter) within easy reach. This effectively shortens the daily maintenance time and increases the equipment's availability.
A: According to the actual operation requirements, different heights of gantry frames, tires of different brands (solid or pneumatic), various brands of lifting devices (such as side cranes, top cranes, and rotating cranes), as well as more advanced intelligent management systems (such as fleet management systems and weighing systems) can be selected.
